Power Meter Operation
Making Measurements with the Agilent E-Series Power Sensors
Agilent E4419B User’s Guide 2-17
10. You must set the display to the type of measurement you require.
This can either be a direct channel measurement, a ratio
measurement of both channels, or a difference measurement
between both channels. Use the following key presses:
Press , . Select the appropriate softkey for
the measurement you require, either , , , , or ,
then , or .
11. The measurement result is now displayed.
Example
To make a measurement on channel A using an Agilent E-series power
sensor. The frequency of the signal to be measured is 100 MHz.
• Disconnect the power sensor from any source.
• Press .
• Press .
• Connect the power sensor to the POWER REF output.
• Press , .
• Press , . Use the , , and
hardkeys to enter 100. Press .
• Connect the power sensor to the signal to be measured.
• The measurement result is now displayed.
Meas
Setup
Input Select
A B A/B B/A
More
A-B
B-A
Zero
Cal
Zero A
Cal
Cal A
Frequency
Cal Fac
A Freq
MHz
