Replacement Procedure
Binding Post Sgl Replacement
Binding Post Sgl Replacement
Tools Required
• Torque screwdriver, TORX T10
• Torque screwdriver, TORX T20
• Box torque wrench, 7 mm
• Box torque wrench, 5/8 inch
• Box torque wrench, 3/8 inch
Removal Procedure
Refer to Figure 6-16 for this procedure.
Step 1. Remove the 3/4 Rack Module Top as described in “3/4 Rack Module Top Replacement” on
page 90.
Step 2. Remove the A3 Analog Daughter Board as described in “A3 Analog Daughter Board
Replacement” on page 94.
Step 3. Remove the A2 Analog Board as described in “A2 Analog Board Replacement” on
page 96.
Step 4. Remove the Front Panel as described in “Front Panel Assembly Removal” on page 98.
Step 5. Remove the 3/8 inch nut (item 1) and washer (item 2) fastening the Binding Post Sgl.
Step 6. Slide the Binding Post Sgl (item 3) from the Front Panel Assembly.
Replacement Procedure
Step 1. Reverse the order of the removal procedure.
NOTE When you fasten the Binding Post Sgl with the 3/8 inch nut and washer, set box torque
wrench's torque to 17.4 in-lb.
