5Replaceable Parts
106 E4416A/E4417A Power Meters Service Guide
Replacing the Front Panel Power Sensor Cable Assemblies
1 Remove the front panel from the power meter. (Refer to “Removing the A3
Front Panel Assembly” on page 105 for details on removing the front panel).
2 Replace the power sensor cable assembly(s) using the replacement kit.
screw
tab
NOTE
After replacing a front panel assembly, the display brightness and contrast must be
adjusted. Refer to Chapter 3, “Display Brightness and Contrast Adjustment” for further
information.
Front panel sensor retaining
clip recess
