B Equipment Required For Performance Tests And Adjustments
B-132 E4416A/E4417A Power Meters Service Guide
Summary Table
The following table summarizes the equipment required for all performance
tests (P) and adjustments (A). If alternative equipment is used it must meet
the critical specifications shown in the table.
Ta bl e B -1 Equipment Required For Performance Tests And Adjustments
Equipment Required Model Number Critical Specification Usage
Digital Multimeter Agilent 3458A Range 0 to 20 V
Resolution 0.01 mV
P and A
DC Calibrator
Datron 4000A
or
Fluke 5700A/5720A
P
Range Calibrator
Agilent 11683A
or
Agilent 11683A
Opt H01
Option H01 is essential for accurate verification.
(See analysis in Appendix D. The Standard
11683A can be used for indication only.
P
Frequency Calibrator Agilent 53132A Range 0.1Hz to 225 MHz
Resolution 0.01 Hz
P and A
Power Meter Agilent 432A Range 1 mW
Transfer Accuracy 0.2%
Internal bridge resistance must be known for 100
Ω and 200 Ω settings. For further information refer
to Appendix A.
P and A
Thermistor Mount Agilent 478A Opt
H75/H76 or
Agilent 8478B Opt H01
SWR<1.05 at 50 MHz
Accuracy ±0.2% at 50 MHz
VRC must be known for thermistor bridge settings
of 100 Ω and 200 Ω. For further information refer to
Appendix A.
P and A
Power Sensor E9321A P
30 dB Attenuator Agilent 11708A
or
Agilent 8491A Opt 030
P
