52 5977 Series MSD Operation Manual
3 Operating in Electron Ionization (EI) Mode
ChemStation IP Displays the IP address for the MassHunter Data Acquisition.
GC IP Address Displays the IP address for the GC.
Ping gateway Checks communication with the gateway.
Ping ChemStation Checks communication with the MassHunter Data Acquisition.
Ping GC Checks communication with the GC.
MAC Address Displays the MAC address of the SmartCard in the MSD.
Reboot with new network
settings
Reboots the system and saves the new network settings.
Table 10 Version menu
Action Description
Control firmware Displays the MSD firmware version.
Operating system Displays the MassHunter Data Acquisition operating system version.
Front panel Displays the version of the LCP.
Log amplifier Displays version information.
Sideboard Displays the sideboard type.
Mainboard Displays the mainboard type.
Serial number Is assigned to the MSD by MassHunter Data Acquisition
Configuration dialogue.
Table 11 Controller menu
Action Description
Reboot controller Starts the LAN/MS control card.
Test LCP? Initiates a diagnostic test of the two-line display.
Test HTTP link to GC/MSD
ChemStation?
Checks the status of the HTTP server.
Table 9 Network menu (continued)
Action Description
