Page #182 background imageLoading...
Page #182 background image
Agilent InfinityLab LC Series VWD User Manual 182
12 Hardware Information
Interfaces
Special Interfaces
There is no special interface for this module.
Table 17 ERI signal distribution
Pin Signal Description
1 START REQUEST (L) Request to start injection cycle (for example, by start key on any
module). Receiver is the autosampler.
2 STOP (L) Request to reach system ready state as soon as possible (for
example, stop run, abort or finish and stop injection). Receiver is any
module performing run-time controlled activities.
3 READY (H) System is ready for next analysis. Receiver is any sequence con-
troller.
4 POWER ON (H) All modules connected to system are switched on. Receiver is
any module relying on operation of others.
5Not used
6 SHUT DOWN (L) System has serious problem (for example, leak: stops pump).
Receiver is any module capable to reduce safety risk.
7 START (L) Request to start run / timetable. Receiver is any module perform-
ing run-time controlled activities.
8 PREPARE (L) Request to prepare for analysis (for example, calibration, detec-
tor lamp on). Receiver is any module performing pre-analysis activi-
ties.
