Agilent InfinityLab LC Series VWD User Manual 92
7Error Information
Detector Error Messages
Wavelength calibration setting failed
Error ID: 7310
The intensity maximum was not found during wavelength calibration.
Calibration 0 Failed: Zero-order calibration failed.
Calibration 1 Failed: 656 nm calibration failed.
Probable cause Suggested actions
1
Lamp is OFF.
Switch on the lamp.
2
Incorrect flow cell installation.
Ensure the flow cell is installed correctly.
3
Flow cell contamination or air bubbles.
Clean/replace flow cell windows or remove air
bubbles.
4
Intensity too low.
Replace lamp.
5
Current step value too far from maximum.
• Repeat the calibration.
• Please contact your Agilent service represen-
tative.
6
Misaligned/defective grating assembly.
Please contact your Agilent service representa-
tive.
7
Defective main board.
Please contact your Agilent service representa-
tive.
