Agilent InfinityLab LC Series Vialsamplers User Manual 273
8Maintenance
Replace the Sample Cooler/Sample Thermostat
7 Slide the new cooler/thermostat halfway into the sam-
pler and connect the power and the data cable.
Damage to the cables
Do not bend or pinch the cables.
Make sure that the Sample Cooler/Sample Thermostat
fits perfectly in the sampler.
8 Slide the cooler/thermostat all the way into the sampler,
making sure that the cables don’t get jammed between
the metal parts.
9 Fix the unit with the four screws. 10 Reconnect the condensate tubing.
For information on proper condensate handling, see “Install
the Sample Cooler/Sample Thermostat” on page 117.
