Vial Drawers and Trays
Vial Drawers and Trays
List of Drawers and Trays
Supported drawers for the module:
Drawer Combinations
Drawers can be installed in any combination enabling both 2 mL- and 6 mL-vials
to be used simultaneously. The only exception is the usage of the classical
drawer option (100 x 2
mL). This option can't combine with the other drawers.
Numbering of Vial Positions
The standard 2*66 vial drawers have 132 vial positions from P1-A1-P2-F11.
However, when using two drawers, the numbering convention is slightly different.
The vial positions of the right-hand drawer begin at position P2-A1 as follows:
Left-hand Drawer for 66 x 2 mL Vials: P1-A1 to P1-F11
Left-hand Drawer for 18 x 6 mL Vials: P1-A1 to P1-C6
Right-hand Drawer for 66 x 2 mL Vials: P2-A1 to P2-F11
Right-hand Drawer for 18 x 6 mL Vials: P2-A1 to P2-C6
Drawer for 50 x 2 mL Vials Classic Left: Vial 1-50
p/n Description
G7129-60010 Drawer for 66 x 2 mL Vials
G7129-60110 Drawer for 18 x 6 mL Vials
G7129-68210 Classic Vial Drawer Kit
G7129-60210 Classic Drawer for 50 x 2 mL Vials, Left
G7129-60220 Classic Drawer for 50 x 2 mL Vials, Right
G7129-60000 External Tray for 5 x 2 mL Vials
Install all drawers for best cooling performance.
