64 Agilent InfinityLab LC Series 1260 Infinity II Isocratic- and Quaternary Pumps User Manual
3
Using the Pump
Setting up the Pump with the Instrument Control Interface
Instrument Signals
The following pump signals are displayed:
Table 9 Pump signals (isocratic pump)
Flow The current solvent flow rate (in mL/min).
Pressure The current pump ressure (in bar, psi or MPa, see “Instrument
Configuration” on page 62).
Ripple The current ripple (in %).
Pressure Limit The current maximum pressure limit.
Table 1 0 Pump signals (quaternary pump)
Flow The current solvent flow rate (in mL/min).
Pressure The current pump ressure (in bar, psi or MPa, see “Instrument
Configuration” on page 62).
Ripple The current ripple (in %).
Pressure Limit The current maximum pressure limit.
Composition A:B The contributions of channels A and B to the current solvent composition.
Composition C:D The contributions of channels C and D to the current solvent composition.
