Agilent Technologies MS40+ User Manual

Technical Information
Technical Data
5
MS40+ Single Stage Rotary Vane Pumps User Manual / 87-901-008-01 (H.00) 64/104
Technical Data
The following table lists the main technical data of the MS40+ Single
Stage Rotary Vane Pumps.
Tab. 1
TECHNICAL DATA RPM UNITS 9499225 9499240 9499241
PUMPING SPEED (at 5 mbar inlet pressure) 1450 m
3
/h 40 40 40
ULTIMATE TOTAL PRESSURE * mbar 5x10
-2
5x10
-2
5x10
-2
OIL CAPACITY min/max l 1 1 1
ROTATIONAL FREQUENCY min/max Hz 40-60 40-60 40-60
NOISE LEVEL
dB(A)
≤ 62 ≤ 62 ≤ 62
IP Value 20
Installation category II
Pollution degree
2
OPERATING TEMPERATURE RANGE °C 12 – 40 12 – 40 12 – 40
WEIGHT Kg 33 33 33
lb 72.7 72.7 72.7
INLET FLANGE DN 25KF 40KF 40KF
EXHAUST FLANGE DN 25KF 25KF 25KF
Main Dimensions:
- length mm 418 418 418
- width mm 297 297 297
- height mm 228 228 228
Nominal Input Voltage V 200-240 200-240 200-240
Input frequency Hz 50 / 60 50 / 60 50 / 60
Max input power VA 1200 1200 1200
Indoor Use Only
Max Altitude 2000m
* According to PNEUROP 6602
** At ultimate total pressure, 20 °C (68 °F) room temperature
