Technical Information
Technical Data
5
MS40+ Single Stage Rotary Vane Pumps User Manual / 87-901-008-01 (H.00) 65/104
Dimensions
The following figure shows the pumps layout and dimensions:
Figure 4 MS40+ Single Stage Rotary Vane Pumps layout
Figure 5 MS40+ Single Stage Rotary Vane Pumps dimensions
Electronic controller
Electric motor
Pumping block
Outlet flange
Air filter
Oil level indicator
Inlet flange
