Technical Information
Pump Electronic Controller
5
MS40+ Single Stage Rotary Vane Pumps User Manual / 87-901-008-01 (H.00) 85/104
Input/Output Communications
P1 – I/O
Tab. 5
PIN N. SIGNAL NAME IN / OUT
1 Interlock Status (N.O. relay contact) out
2 Speed setting (0-10V) in
3 Oil level (relay contact) out
4 Start command (24V-) in
5
Ground
out
6 Interlock Status (N.O. relay contact) out
7 Oil level (relay contact) out
8
Start command (24+)
in
9
24V
out
 Interlock: N.O. Relay contact – It is closed as soon as the
rotational frequency exceed the threshold defined with window
no.102 (plus histerisys defined by window 105).
 Speed setting: Pump speed setting – linear setting between 1V=15
Hz and 9 V= Win.120 setting:
 High speed (60 Hz): Vin>9 V
 Low speed (40 Hz): Vin<1 V
