Technical Information
RS 232/RS 485 Communication Description
5
MS40+ Single Stage Rotary Vane Pumps User Manual / 87-901-008-01 (H.00) 92/104
WIN TYPE R/W DESCRIPTION
206 N R ERROR CODE: 128: Rotor blocked; 64: shortcircuit; 32: Undervoltage/Overvoltage;
16: Motor overtemp; 8: Verify line; 4: Controller overtemp; 2: Bus Undervoltage;
1: overcurrent
207 N R OUTPUT FREQUENCY [rpm]
216 N R CONTROLLER TEMPERATURE [°C]
222 N R POWER SUPPLY TEMPERATURE [°C]
225 N R OIL LEVEL (0=level ok; Bit 0: underlevel; Bit 1: maintenance)
233 N R ROTATIONAL FREQUENCY [rpm]
300 N R CYCLE TIME [min]
301 N R CYCLE NUMBER
302 N R PUMP LIFE [h]
305
N
R
TIME WITH OIL UNDER LEVEL [min]
306 N R TIME WITH DIRTY FILTER [min]
307 N R TIME CONTROLLER STAND BY
319 A R CONTROLLER MODEL NUMBER
320 A R PUMP MODEL NUMBER
321 A R PUMP SPECIAL MODEL NUMBER
322 A R PUMP SERIAL NUMBER
323
A
R
CONTROLLER SERIAL NUMBER
358 N R MAINTENACE TIMER [hours]
362 N R LAST HOUR TEMPERATURE AVERAGE [°C]
364 N R LAST HOUR AVERAGE POWER [W]
365 N R LAST HOUR AVERAGE FREQUENCY [Hz]
382 N R LAST HOUR AVERAGE TEMPERATURE (°C)
384 N R AVERAGE TEMPERATURE DURING PUMP LIFE (°C)
406
A
R
PROGRAM LISTING CODE & REVISION
407 A R PARAMETER LISTING CODE & REVISION
503 N RW RS485 SERIAL ADDRESS SETTING [0-31]
504 L RW SERIAL TYPE SELECT (0=RS232; 1=RS485)
