Agilent Technologies N5182A Service Guide

Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Replaceable Parts
Assemblies and Hardware Options
2-23
Disassembled Rear Panel View
Table 2-8 Disassembled Rear Panel View
Item No. Description Qty Part Number
1 Rear Panel - N5161A/81A
Rear Panel - N5162A/82A
Rear Panel - N5183A
1
1
1
N5180-00002
N5180-00017
N5180-00006
2 Screw-Machine M3.0 8 -PN-TX
N5161A/81A
N5162A/82A
N5183A
4
10
10
0515-0372
3 Screw-Machine 4-40 (N5162A/82A only) 4 2200-0139
4 Washer Lock .505ID (BNC connectors on rear-panel)
N5161A/81A
N5162A/82A
N5183A
8
15
9
2190-0068
5 Nut-Hex 1/2-28 (BNC connectors on rear-panel board)
N5161A/81A
N5162A/82A
N5183A
8
15
9
2950-0054
6 Rear-Panel Hole Plug 1 6960-0517
7 Rear-Panel BNC Hole Plug (N5183A only) 1 N/A
