Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Assembly Replacement
A4 Internal Memory Card (N5162A/82A only)
3-52
A4 Internal Memory Card (N5162A/82A only)
Tools Required
• T-10 driver
Removal Procedure
Refer to Figure 3-29 for this procedure.
1. Disconnect the power cord.
2. Remove the covers from the signal generator. Refer to ”Outer Cover” on page 3-4 and ”Inner Bottom Cover” on page 3-8.
3. Place the signal generator flat and upside down with the rear panel facing you.
4. Using the T-10 driver, remove the screw (1) that attaches the A4 Internal Memory Card to the A3 RF assembly.
5. Remove the A4 Internal Memory Card by gently rocking it side to side to release the pin.
Replacement Procedure
1. Reverse the order of the removal procedure.
CAUTION The A4 Internal Memory Card pin can be re-installed incorrectly. To insure proper installation carefully align the connector
on the A4 Internal Memory Card with the connector on the A3 RF assembly.
2. Torque all screws to 9 in–lbs.
3. Perform the post-repair performance tests that pertain to this replacement procedure, see Chapter 4, Post-Repair Procedures and
Performance Verification.
