Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Replaceable Parts
Assemblies and Hardware Options
2-14
Cables
This section lists part numbers for the cables in your signal generator.
Table 2-6
Reference
Designator
Input Output Part Number Page Number
B1W1
a
Wire Cable, B1 Fan A1 Power Supply (part of B1) 2-16 & 2-17
B2W1
a
Wire Cable, B2 Fan A1 Power Supply (part of B2) 2-16 & 2-17
B3W1
a
Wire Cable, B3 Fan A1 Power Supply (part of B3) 2-16 & 2-17
B4W1
a
Wire Cable, B4 Fan A1 Power Supply (part of B4) 2-16 & 2-17
W1 Ribbon Cable, Front Panel A3 RF Assembly 8121-1398 2-19 & 2-20
W2 Front Panel (USB) A3 RF Assembly 8121-1396 2-19 & 2-20
W3
(N5182A only)
Front Panel (I Input) A2J15 8121-0642 2-16 & 2-17
W4
(N5182A only)
Front Panel (Q Input) A2J16 8121-0642 2-16 & 2-17
W5
(N5182A only)
Semi-Rigid Cable, A3 RF Assembly A2 Vector Modulation N5180-20016 2-17
W6
(N5182A only)
Semi-Rigid Cable, A3 RF Assembly A2 Vector Modulation N5180-20025 2-17
W7
(N5162A/82A
only)
Semi-Rigid Cable, A3 RF Assembly A2 Vector Modulation N5180-20026 2-16 & 2-17
W8 Ribbon Cable, A3 RF Assembly (GPIB) A5 CPU 8121-1397 2-19 & 2-20
W9
(N5183A only)
Semi-Rigid Cable, 2.4mm RF Connector Mechanical Attenuator N5180-20046 2-18
W10
(N5183A only)
Semi-Rigid Cable, 3.5mm RF Connector Mechanical Attenuator N5180-20057 2-18
W11
(N5183A only)
Semi-Rigid Cable, Type-N RF Connector Mechanical Attenuator N5180-20088 2-18
W12
(N5183A only)
Semi-Rigid Cable, A3 RF Assembly A7 Micro Desk Low Band Coupler N5180-20040 2-18
W13
(N5183A only)
Semi-Rigid Cable, A3 RF Assembly A7 Micro Deck 20 GHz Doubler N5180-20039 2-18
W14
(N5183A only)
A7J15 A3 RF Assembly 8121-1578 2-18
W15
(N5183A only)
A7J14 Rear Panel (ALC Input) 8121-0859 2-18
W16
(N5162A/82A
Option 012
only)
Semi-Rigid Cable, LO In Rear Panel N5180-20140 2-16
