Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Replaceable Parts
Assemblies and Hardware Options
2-3
Assemblies and Hardware Options
Refer to Table 2-1 for N5161A and N5162A signal generators.
Refer to Table 2-2 thru Table 2-4 for N5181A and N5182A signal generators.
Refer to Table 2-5 for N5183A signal generators.
Table 2-1 N5161A/62A
Description Option 503 Option 506
Part Number Page Number Part Number Page Number
Front Panel - N5161A (Analog) N5160-60005 2-9 N5160-60006 2-9
Front Panel - N5162A (Vector) N5160-60007 2-9 N5160-60008 2-9
Power Switch N5180-60022 2-7 N5180-60022 2-7
USB Board N5180-60023 2-7 N5180-60023 2-7
A1 Power Supply N5180-60060 2-9 N5180-60060 2-9
A2 Vector Module Assembly (N5162A
only)
N5180-69006 2-9 N5180-69006 2-9
A3 RF Assembly 1EM All (Any
combination of options or no
options)
a
(rear panel output)
a
The replacement of the A3 RF assembly requires firmware ≥A.01.42. To avoid configuration errors, download firmware ≥A.01.42 prior to
replacing the A3 assembly. If the A3 RF assembly is replaced prior to downloading firmware ≥ A.01.42, downloading firmware ≥A.01.42
and cycling the power should correct any configuration errors.
N5180-69170 2-12 N5180-69170 2-12
A3BT1 Lithium Battery 1420-0356 2-12 1420-0356 2-12
A4 Internal Memory Card (N5162A
only)
1819-0693 2-12 1819-0693 2-12
A5 CPU
b
b
The replacement of the A5 CPU requires firmware ≥A.01.60.
N5180-60190 2-12 N5180-60190 2-12
A9 Interface Board N5160-60009 2-7 N5160-60009 2-7
B1 thru B4 Fan (each)
c
c
There are two different fans structured to this part number. The fan currently shipping has a thickness of 20mm. The fan that shipped
previously had a thickness of 25mm. Both fans are acceptable to use.
N5180-60026 2-9 N5180-60026 2-9
CVR, Front Panel N5180-40012 2-29 N5180-40012 2-29
