Agilent Technologies N5182A Service Guide

Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Replaceable Parts
Assemblies and Hardware Options
2-4
Table 2-2 N5181A/82A
Description Option 501 Option 503 Option 506
Part Number Page Number Part Number Page Number Part Number Page Number
Front Panel - N5181A (Analog) N5180-60110 2-10 N5180-60110 2-10 N5180-60110 2-10
Front Panel - N5182A (Vector) n/a n/a N5180-60111 2-10 N5180-60111 2-10
Key Pad N5180-60021 2-8 N5180-60021 2-8 N5180-60021 2-8
Power Switch N5180-60022 2-8 N5180-60022 2-8 N5180-60022 2-8
USB Board N5180-60023 2-8 N5180-60023 2-8 N5180-60023 2-8
LCD N5180-60024 2-8 N5180-60024 2-8 N5180-60024 2-8
A1 Power Supply N5180-60060 2-10 N5180-60060 2-10 N5180-60060 2-10
A2 Vector Module Assembly
(N5182A only)
n/a n/a N5180-69006 2-10 N5180-69006 2-10
A3 RF Assembly See Table 2-3 or Table 2-4 for serial number specific assemblies.
A3BT1 Lithium Battery 1420-0356 2-13 1420-0356 2-13 1420-0356 2-13
A4 Internal Memory Card (N5182A
only)
n/a n/a 1819-0693 2-13 1819-0693 2-13
A5 CPU
a
a
The replacement of the A5 CPU requires firmware ≥A.01.60.
N5180-60190 2-13 N5180-60190 2-13 N5180-60190 2-13
A6 DC-AC Inverter Interface N5180-60025 2-8 N5180-60025 2-8 N5180-60025 2-8
B1 thru B4 Fan (each)
b
b
There are two different fans structured to this part number. The fan currently shipping has a thickness of 20mm. The fan that shipped previously had a thickness of 25mm. Both fans
are acceptable to use.
N5180-60026 2-10 N5180-60026 2-10 N5180-60026 2-10
CVR, Front Panel N5180-40012 2-29 N5180-40012 2-29 N5180-40012 2-29
Table 2-3 N5181A/82A Instrument Serial Number < xx4818xxxx
Description Option 501 Option 503 Option 506
Part Number Page Number Part Number Page Number Part Number Page Number
A3 RF Assembly UNM
ab
(front panel output)
a
The replacement of the A3 RF assembly requires firmware ≥A.01.42. To avoid configuration errors, download firmware ≥A.01.42 prior to replacing the A3 assembly. If the A3 RF
assembly is replaced prior to downloading firmware ≥A.01.42, downloading firmware ≥A.01.42 and cycling the power should correct any configuration errors.
N5180-69122 2-13 N5180-69122 2-13 N5180-69124 2-13
A3 RF Assembly UNM with 1EL, or
UNU, or UNT (front panel output)
N5180-69122
2-13
N5180-69122
2-13 N5180-69124 2-13
A3 RF Assembly UNM with
1EL, or UNU, or UNW, or UNT, or
all & any combination or all of the
following options; UNV, UNZ, 1EA,
1EQ and 099
a
(front panel output)
N5180-69123 2-13 N5180-69123 2-13 N5180-69125 2-13
A3 RF Assembly 1EM All (Any
combination of options or no
options)
a
(rear panel output)
N5180-69170 2-13 N5180-69170 2-13 N5180-69170 2-13
