Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Assembly Replacement
Rear Panel (N5161A/81A)
3-22
Rear Panel (N5161A/81A)
Tools Required
• T-10 driver
• 5/8” hex-nut driver
Removal Procedure
Refer to Figure 3-11 for this procedure.
1. Disconnect the power cord.
2. Remove the covers from the signal generator. Refer to ”Outer Cover” on page 3-4, ”Inner Top Cover” on page 3-6, and ”Inner Bottom
Cover” on page 3-8.
3. Place the signal generator flat with the rear panel facing you.
4. Using the 5/8” hex-nut driver, remove the nuts and washers (1) securing the A3 RF assembly BNC’s to the rear panel.
5. Using the T-10 driver, remove the four screws (2) securing the rear panel to the signal generators chassis.
6. Pull the rear panel away from the signal generator’s chassis.
Replacement Procedure
1. Reverse the order of the removal procedure.
2. Torque all screws to 9 in–lbs.
3. Torque all BNC connectors to 8 in–lbs.
4. Perform the post-repair performance tests that pertain to this replacement procedure, see Chapter 4, Post-Repair Procedures and
Performance Verification.
