Agilent Technologies N5182A Service Guide

Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Replaceable Parts
Assemblies and Hardware Options
2-5
b
The replacement of the A5 CPU requires firmware ≥A.01.60.
Table 2-4 N5181A/82A Instrument Serial Number > xx4818xxxx
Description Option 501 Option 503 Option 506
Part Number Page Number Part Number Page Number Part Number Page Number
A3 RF Assembly UNM
a
(front panel output)
N5180-69166 2-13 N5180-69166 2-13 N5180-69168 2-13
A3 RF Assembly UNM with 1EL, or
UNU, or UNT (front panel output)
N5180-69166 2-13 N5180-69166 2-13 N5180-69168 2-13
A3 RF Assembly UNM with
1EL, or UNU, or UNW, or UNT, or
all & any combination or all of the
following options; UNV, UNZ, 1EA,
1EQ and 099
a
(front panel output)
N5180-69167 2-13 N5180-69167 2-13 N5180-69169 2-13
A3 RF Assembly 1EM All (Any
combination of options or no
options)
a
(rear panel output)
N5180-69170 2-13 N5180-69170 2-13 N5180-69170 2-13
a
The replacement of the A3 RF assembly requires firmware ≥A.01.42. To avoid configuration errors, download firmware ≥A.01.42 prior to replacing the A3 assembly. If the A3 RF
assembly is replaced prior to downloading firmware ≥A.01.42, downloading firmware ≥A.01.42 and cycling the power should correct any configuration errors.
Table 2-5 N5183A
Description Option 520 Option 532 Option 540
Part Number Page Number Part Number Page Number Part Number Page Number
Front Panel N5180-60112 2-10 N5180-60112 2-10 N5180-60112 2-10
Key Pad N5180-60021 2-8 N5180-60021 2-8 N5180-60021 2-8
Power Switch N5180-60022 2-8 N5180-60022 2-8 N5180-60022 2-8
USB Board N5180-60023 2-8 N5180-60023 2-8 N5180-60023 2-8
LCD N5180-60024 2-8 N5180-60024 2-8 N5180-60024 2-8
A1 Power Supply N5180-60060 2-10 N5180-60060 2-10 N5180-60060 2-10
A3 RF Assembly N5180-69077 2-13 N5180-69077 2-13 N5180-69077 2-13
A3BT1 Lithium Battery 1420-0356 2-13 1420-0356 2-13 1420-0356 2-13
A5 CPU
a
N5180-60190 2-13 N5180-60190 2-13 N5180-60190 2-13
A6 DC-AC Inverter Interface N5180-60025 2-8 N5180-60025 2-8 N5180-60025 2-8
A7 Micro-Deck - Option UNM (front
panel output)
N5180-69041 2-11 N5180-69043 2-11 N5180-69043 2-11
A7 Micro-Deck - Option 1EM (rear
panel output) 3.5mm RF Connector
N5180-69042 2-11 n/a n/a n/a n/a
A7 Micro-Deck - Option 1EM (rear
panel output) 2.4mm RF Connector
n/a n/a N5180-69044 2-11 N5180-69044 2-11
A7 Micro-Deck - Option 1EM (rear
panel output) Type N RF Connector
N5180-69121 2-11 n/a n/a n/a n/a
