Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Replaceable Parts
Assemblies and Hardware Options
2-6
A8 BNC Bypass Board E8251-63665 2-11 E8251-60061 2-11 E8251-60061 2-11
B1 thru B4 Fan (each)
b
N5180-60026 2-11 N5180-60026 2-11 N5180-60026 2-11
CVR, Front Panel N5180-40012 2-29 N5180-40012 2-29 N5180-40012 2-29
RF Output Connector (2.4mm) n/a n/a n/a n/a 5063-1700 n/a
RF Output Connector (Type N) 08559-60002 n/a 08559-60002 n/a n/a n/a
RF Output Connector (3.5mm) 08673-60040 n/a 08673-60040 n/a n/a n/a
a
The replacement of the A5 CPU requires firmware ≥A.01.60.
b
There are two different fans structured to this part number. The fan currently shipping has a thickness of 20mm. The fan that shipped previously had a thickness of 25mm. Both fans
are acceptable to use.
Table 2-5 N5183A
