Agilent Technologies PSA Series Installation Note

Installation Note E4440-90613 5
Switchable Microwave Preselector Bypass Installation Kit
Contents
Quantity
Description Agilent Part
Number
1 Installation Note This note
1 Option Upgrade Entitlement Certificate 5964-5141
1 User's Guide, Volume 1 ---
1 Specifications Guide ---
1 3 dB Attenuator 0955-0246
1 Preselector Bypass Mixer 1NB7-8539
1 Mixer Bias Board E4440-60254
1 Option Driver Assembly E4440-60459
1 SW 3, Switch coax N1810-60052
1 SW 5, Switch 50 GHz 87222-60015
1 Bracket, mixer E4440-00062
1 Bracket, coax Switch E4440-00076
1 Bracket, switch E4440-00063
1 W89, Cable, coax, Switch SW3 bottom port to
RHYTHM/SBTX
E4440-60373
1 W90, Cable, flat flex, Preselector Bypass Mixer to Mixer
Bias Board
8150-5698
1 W92, Cable, Ribbon, Option Driver Assembly J8 to SW5 E4440-60455
1 W93, Cable, coax, Preselector Bypass Mixer to Switch 3
Coax Switch top port
E4440-60298
1 W94, Cable, coax, Coax Switch SW3 center connector to
3RD Converter
E4440-60373
1 W95, Cable, ribbon, Option Driver Assembly J7 to Mixer
Bias Board (opt 123)
E4440-60397
1 W96, Cable, ribbon, Driver board J9 to Coax switch E4440-60427
1 W98, Cable, semi-rigid, Preselector Bypass Mixer LO IN to
W46 / 3 dB attenuator
E4446-20074
1 W99, Cable, semi-rigid, Preselector Bypass Mixer to Switch
SW5 Port 4
E4446-20318
1 W100, Cable, semi-rigid, Switch SW5 port 1 from
attenuator. (For instruments that do not have opt 110)
E4446-20071
