6 Installation Note E4440-90613
Switchable Microwave Preselector Bypass Installation Kit
1 W101, Cable, semi-rigid, Switch SW4 port 4 to Switch SW5
port 1 (For instruments that have Opt 110)
E4446-20081
1 W105, Cable, semi-rigid, Switch SW5 port 2 to W34 cable
that goes to A10 RYTHM/SBTX
E4446-20080
1 W46, Cable semi-rigid, A12 FELOMA to W98 / 3 dB
attenuator
E4440-20035
1 Thermal Pad N1996-40018
12 Screw, M3 X 0.5 8 MM-LG 0515-0372
2 Screw, M3 X 0.5 18 MM-LG 0515-0666
2 Screw, M3.5 X 0.6 8 MM-LG 0515-0458
3 Screw, M2.5 X 0.45, 6 MM-LG 0515-1934
2 Screw, M3 X 0.5, 6 MM-LG 0515-0430
1 Clamp, cable, PVC 1400-0611
2 SMA Hole Plug 6960-0076
Quantity
Description Agilent Part
Number
