6 Single-wheel power hoe 3100 Edition 03.956 Single-wheel power hoe 3100 Edition 03.95
Designation of Parts
Figure A and B
1 Fuel tank
2 Fuel tank cap
3 Handlebar
4 Tool kit
5 Tensioning lever for handlebar side adjustment
6 Hexagonal screw for handlebar height adjustment
7 Oil bath air filter
8 Gear shift lever for speed ratios
9 Shift lever for tilling drive
10 Tilling attachment
11 Cap for chain gear housing
12 Starter handle
13 Drive-wheel
14 Cooling-air screen
15 Exhaust
16 Location nut for front weight mounting
17 Engine type plate
18 Square nut for handlebar height adjustment
19 Name plate/ID no.
20 Fuel tap
21 Carburetor
22 Carburetor – tickler
23 Spark plug/spark plug connector
24 Hexagonal screw for drive-wheel
25 Mechanical gearbox – oil drain screw
26 Mechanical gearbox – oil filler screw/oil control screw
