101
Configuring the Station
5. Option Input / Relay Output Settings
5.1 Option Input
5.1.1 Option Input Advanced Settings
How to configure Option Input
1. Select the option input to be configured in "Option Input #"
• The settings of the selected option input are displayed.
2. Configure each item.
3. When configuration is complete, click [Update].
■ Name
Important
• Do not change the "Function," "Detection Time Range," or "Detection time [msec / sec]♦" settings for contact input 6 on IX-
DVF-2RA, IX-DVF-RA, IX-SSA-2RA, or IX-SSA-RA.
Description Configure the terminal name for the input terminal.
Settings 1 - 24 alphanumeric characters
Default values —
To Next Page
