Aiphone IX-SS-2G User Manual

89
Other
Appendix
5
Specifications
Power IX-SS-2G: PoE (IEEE802.3af Class0 standard)
IX-DV, IX-DVF(-*), and IX-SSA(-*): PoE (IEEE802.3af/at Class0 standard)/PS-2420A
Consumption current IX-SS-2G: 33 mA during standby, 70 mA during maximum
IX-DV and IX-DVF(-*): For PoE, 55 mA during standby (77 mA during normal video/audio
recording), 155 mA during maximum
For PS-2420A, 94 mA during standby (140 mA during normal video/audio recording), 300 mA
during maximum
Communication Hands-free
Camera (IX-DV and IX-DVF(-
*) only)
1/3-type color CMOS, SXVGA 1280x960 (approximately 1.2 million pixels)
Minimum illumination
(IX-DV and IX-DVF(-*) only)
5 lux
LAN Ethernet (10BASE-T, 100BASE-TX), Auto MDI/MDI-X-compatible
Audio codec G.711 (u-law, A-law), G.722
Video codec
(IX-DV and IX-DVF(-*) only)
H.264/AVC, Motion-JPEG
Protocol IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, RTSP, RTP, RTCP, IGMP, MLD, SMTP, SFTP,
DHCP, NTP, DNS
Encryption system TLS1.0, TLS1.1, TLS1.2
Packet transmission system Unicast and multicast (IX-DV and IX-DVF(-*) only)
Number of called stations 20 stations × 10 groups
Operating temperature -40 to +60°C
Materials IX-SS-2G: Main unit (fire-retardant resin), panel (stainless steel, vertical alignment finished)
IX-DV: Main unit (fire-retardant resin), main unit cover (die cast aluminum)
IX-DVF(-*) and IX-SSA(-*): Main unit (fire-retardant resin), panel (stainless steel, vertical
alignment finished)
Color IX-SS-2G: Main unit (black), panel (silver)
IX-DV: Main unit (black), main unit cover (dark sepia metallic)
IX-DVF(-*) and IX-SSA(-*): Main unit (black), panel (silver)
Dimensions IX-SS-2G: 120 mm (4-3/4") [W], 120 mm (4-3/4") [H], 2.5 mm (1/8") [D] (exposed area; excluding
projection)
IX-DV: 115 mm (4-1/2") [W], 207 mm (8-1/8") [H], 45 mm (1-3/4") [D] (excluding projection)
IX-DVF and IX-SSA: 150 mm (5-7/8") [W], 265 mm (10-7/16") [H], 2.5 mm (1/8") [D] (exposed
area; excluding projection)
IX-DVF-* and IX-SSA-*: 178 mm (7") [W], 297 mm (11-11/16") [H], 2.5 mm (1/8") [D] (exposed
area; excluding projection)
Weight: IX-SS-2G: Approx. 390 g (0.86 lbs)
IX-DV: Approx. 770 g (1.7 lbs)
IX-DVF: Approx. 1.2 kg (2.7 lbs)
IX-DVF-2RA and IX-DVF-RA: Approx. 1.5 kg (3.3 lbs)
IX-DVF-P: Approx. 1.4 kg (3.1 lbs)
IX-SSA: Approx. 1.2 kg (2.7 lbs)
IX-SSA-2RA and IX-SSA-RA: Approx. 1.5 kg (3.3 lbs)
Water/dust protection class IX-DV: IP54 (JIS C 0920) (dust-resistant/splash-resistant)
IX-DVF(-*), IX-SSA-*, and IX-SS-2G: IP65 (dust-proof/spray-resistant)
Impact protection class IK08 (IX-DV, IX-DVF(-*), IX-SSA(-*), and IX-SS-2G only)
Remarks ONVIF Profile S-compatible (IX-DV and IX-DVF(-*) only)
