Before Using
User Interface
2
Communication Screen
When receiving a call from a video station When receiving a call from an audio station
No. Name Description
1 Priority Indicates the priority level of the current call.
: Urgent, : Priority, : Normal
2 Settings The following items can be adjusted.
(→page 65)
• : Zoom lock
• : Backlight compensation and nighttime sensitivity correction for video
• : Screen brightness
• : Receive volume
• : Mic volume
• : Ringtone
3 Number of incoming calls and
priority
Shows the number of incoming calls and priority. Tap to display the calling stations in
a list and select a station to answer.
(→page 63)
: Urgent, : Priority, : Normal
4 Keypad Tap this to display the keypad. Release the electrical lock
(→page 60) through keypad
input.
5 Unlock Unlock the door.
(→page 60)
6 Primary video display area Shows video from the calling station or associated network camera.
7 Secondary video display area Displays if a network camera is associated with the other station, and the station has a
camera. If the calling station is IX-MV7-* and there is no associated network camera,
the video from this station will be displayed. A different video will be displayed from
what is displayed in the primary video display area.
8 Calling Station Displays the station number, station name, and building name of the calling station. If
the calling station is a Mobile App, "Mobile Apps" is displayed. Also shows the network
camera name if the network camera is linked to the calling station. (The character may
become corrupted depending on the set language.) If the number of characters is long
and is tapped, the display may be scrolled.
9 Time Indicates the current time.
1
10101010
89
17
12
11
13
14
15
16
2
3
4
5
7
6
17
13
14
15
16
18 9
2
4
7
To Next Page
