INSTRUMENT PANEL
1. Turn indicator light (Green)
Flashes when the right/left turn indicator switch is operated.
2. High beam indicator light (Blue)
Turns on when the light switch is on the high beam position.
3. Tachometer
Indicates the engine revolutions per minute (rpm).
4. Speedometer
Indicates the instantaneous vehicle speed.
5. Engine oil indicator light (Red)
(The engine oil indicator is deactivated in this model)
6. Neutral indicador light N (Green)
Activates when the neutral gear is engaged.
7. Fuel reserve (Amber yellow)
Turns on when the fuel level is below 3 liters.
8. Select button
Swaps through the digits/settings when pressed.
9. Odometer/Trip meter
Indicates the total/trip distance travelled.
10. Fuel meter
Indicates the fuel level in the fuel tank.
11. Adjust button
Changes the digits/settings when pressed.
12. Injection system diagnosis indicator (Amber yellow)
Turns on when fuel injection system associated error is detected.
