RIGHT HANDLEBAR
1. Emergency switch (kill switch)
The emergency switch (1) has two positions:
― ON position ( ) enables engine running.
― OFF position ( ) stop the engine from running, cutting off the engine
electric circuit.
To switch to the OFF position press down the switch.
2. Front brake lever
Operate the front brake by gripping brake lever (2) toward the throttle grip.
Simultaneously the stop light in the taillight will light up.
3. Electric start button
Use the electric start button (3) to activate the starter motor. To start the engine,
place the ignition key in the ON position and engage the neutral gear.
4. Throttle grip
The engine speed is controlled through the throttle grip (4) position. To increase the
speed, rotate counter-clockwise (+). Release the grip to reduce the speed.
If the emergency switch is on the OFF position, the engine will not start. Also the
starter motor will not be activated. The instrument panel and the tablet will remain
activated.
