Electrical safety
10
The colours of the wires in the mains lead of the set-top box may
not match the coloured markings on the terminals in your plug,
so you should follow these instructions.
• You must connect the blue wire to the terminal
marked with the letter ‘N’ or coloured black.
• You must connect the brown wire to the terminal
marked with the letter ‘L’ or coloured red.
• You should not connect anything to the earth
terminal of the plug marked with the letter ‘E’ or
coloured green.
If you use a 13-amp (BS1363/A) plug, you must fit a 3-amp fuse
(BS1362), or if you use any other type of plug you must use a
3-amp fuse in the plug, adaptor or in the plug connected to the
mains extension cable.
BLUE
(neutral)
BROWN
(live)
No connection
(earth)
N
E
L
Cable grip
The plug should be approved to
British Standards (BS1363/A).
Fit a 3 amp fuse
Ensure the outer sheath of the mains cable
is securely held by the cable grip
Mains cable
