Parts
12
Parts
Main unit
RF IN
R F OU T SCART OUT RS-232C RESET
AC IN
100-240V
50/60Hz
Front panel
Rear panel
Remote control sensor
RF OUT.
and status indicator window
RF IN. Connects to your aerial
SCART OUT
System reset switch
13A mains plug
Mains cable
(This connects the
set-top box to your TV)
Service connector (for the manufacturer
and anyone who repairs the set-top box)
(to reset the set-top box)
(This connects the set-top
box to your TV or
video recorder)
