Specification
68
Specification
GENERAL
Size
Weight
Power consumption
210 x 141 x 36 mm (W x D x H)
0.5 kg
7 W max
SYSTEM
Processor
Flash memory
SDRAM
MHEG-5 engine
UK Engine
Object carousel support
STI5118 32bit @ 200 MHz
2 Mbyte
16 Mbyte
Compliant with ISO/IEC 13522-5 and
Profile1
Compliant with ISO/IEC 135818-6 and UK DTT Profile
RECEPTION
Frequency range
Signal level
Transmission standards
Demodulation
FEC
Video
Audio
474 - 858 MHz
-82.3 dBm
DVB-T, MPEG-2
COFDM with 2K / 8K FFT mode
All DVB modes
MP@ML, PAL, 4:3/16:9
MPEG Layer I & II 32/44.148 kHz
