5.2 Display during charging of battery pack
1 LED (red) flashes – Battery pack is charged less then 20 %.
LED (red) flashes
1 LED flashes, 1 LED come on – Battery pack is charged between 20 % and 40 %.
1 LED flashes, 2 LEDs come on – Battery pack is charged between 40 % and 60 %.
1 LED flashes, 3 LEDs come on – Battery pack is charged between 60 % and 80 %.
1 LED flashes, 4 LEDs come on – Battery pack is charged between 80 % and 100 %.
5 LEDs come on – Battery pack is fully charged.
The e-motion wheel shuts off automatically if the charger plug [27] is pulled from the charger socket [3].
If a fault occurs during the charging process, all LEDs flash slowly and an acoustic warning tone sounds (refer to
Chapter 5.3).
