1.6 Specifications
Range: 25 km per ISO 7176 - 4
Max. speed: 6 km/h
Drive power: 2 x 60 W
Motor voltage: 24 V
Operating temperature: –25 °C - +50 °C
Max. load capacity: 130 kg
Battery pack
Battery type: Lithium-Ions
Nominal operating voltage: 25.2 V
Charge temperature: 0 °C - 40 °C
Weight of the individual parts
Wheel: 9.2 kg
Battery pack: 1.3 kg
Battery charger: 0.8 kg
Overall weight: 21.0 kg
Range: 25 km per ISO 7176 - 4
(*) The range varies depending on the terrain traversed and the prevailing driving conditions. The stated range can be achieved if driving
conditions are optimal (even terrain, freshly charged batteries, ambient temperature of 20 °C, even travel, etc.).
The e-motion complies with the EC directive for medical products 93/42/EEC.
We reserve the right to make alterations to the technology and design as part of ongoing further developments.
Battery charger
Please refer to the technical notes and instructions in the manual accompanying the charger.
1.7 The most important elements at a glance
(Please unfold the general drawing contained in the envelope)
Wheel Protective cover for battery contacts
LED display 1 Cover 18
Rubber cover of the charger socket 2 Locking pin of the cover 19
Charger socket 3
Lock of the stub axle 4
Remote control (optional)
On/Off button 5 Info button 20
Handle area 6 Display 21
Fins (rear of wheel) 7 Button 2 22
Stub shaft 8 Button 1 23
Push rim 9 Button 0 24
Battery contacts (inside of wheel hub) 10 Reset button 25
Battery pack
Battery pack locking pin 11 Battery charger
Battery pack 12 Housing 26
Protective cover for battery contacts 13 Charger plug 27
Burls of plastic cover 14
Wheelchair (not included in scope of delivery) Anti-tippers (optional)
Bracket with wheel receiver 15 Quickpin 28
Parking brake of wheelchair 16 Receiver fork of bracket 29
Bracket for remote control (optional) 17 Holding rod 30
Clamping piece 31
