30
POWER SUPPLY
Remember to protect the power supplies (brea-
kers, etc) in order to comply with national safety
standards.
WALL MOUNTING
Fix the power supply to the wall using the screws
supplied.
FITTING TO A DIN RAIL
Fit the power supply to the DIN rail as shown in
the diagram.
REMOVING FROM DIN RAIL
To remove the power supply from the DIN rail,
lever it off with a screw driver, as shown in the
diagram.
FIXING THE TERMINAL COVER
Fix the protective terminal cover using the fixing
screws supplied.
