35
T
erminal connections
The power supply must be connected on one
side to the electrical mains and on the other to the
entrance panel audio unit. Make the connections
as shown in the diagram.
POWER SUPPL
Y
230 V
Mains voltage
Ground (to the audio unit)
V
Output voltage (to the audio unit)
