7210 SAS-M Overview
7210 SAS-M Installation Guide Page 13
Figure 2: 7210 SAS-M 24F 2XFP and 7210 SAS-M 24F 2XFP ETR Front Panel
The 7210 SAS-M 24F 2XFP and 7210 SAS-M 24F 2XFP ETR include the following features:
• 24 100/1000 SFP ports and 2 10G XFP ports
• One RJ-45 management port for firmware upgrade or system management
• One RJ-45 console (RS-232 interface) connector for device management
• 7210 SAS-M 24F 2XFP ETR version supports extended temperature range
•Embedded SR OS
• Compact size: 1.5RU height, 19-inch rack-mountable metal enclosure, 10-inch depth
(ETSI)
Crit
SR72029
Note: Except for the labeling, the 7210 SAS-M 24F 2XFP and 7210 SAS-M 24F 2XFP ETR
chassis are identical in terms of front panel appearance.
