Alcatel-Lucent MDR-8000 - Page 59

3-15
Figure 3 - 9 DS3 LBO Wayside DS1 Connectors Location and Pinout
J315
J301
J313
J308 J309 J310 J312
J318
J305
J316 J317 J302
J307
J201
INPUT
FRONT VIEW
51
96
LINE 1 IN RING
LINE 2 IN RING
LINE 3 IN RING
GND
LINE 3 IN TIP
LINE 1 IN TIP
LINE 2 IN TIP
51
96
J202
OUTPUT
FRONT VIEW
GND
LINE 3 OUT TIP
LINE 1 OUT TIP
LINE 2 OUT TIP
LINE 1 OUT RING
LINE 2 OUT RING
LINE 3 OUT RING
LMW-7069F
07/23/02
J301
