3.12.1 2 or 4 Fiber Management Panel
The 2 or 4 fiber management panel provides a direct interface with customers 2 or 4 fiber
equipment. The two fibers on a non-standby radio or four fibers on a hot-standby radio con
-
nect to the two or four fibers from the customers equipment. The 2 or 4 fiber configuration
requires the duplex adapter panel to route the fiber to/from the I/O interface modules. One
duplex adapter panel can accommodate two radio shelves. Customer fiber must have SC
type connectors
3.12.2 2x4 Fiber Switched Management Panel
The 2x4 fiber management panel interfaces the four fibers on a hot-standby shelf with cus-
tomer’s 2-fiber equipment. The 2x4 fiber configuration requires combiner splitter units to
route the fiber to/from the I/O interface modules. One combiner/splitter unit per radio shelf
is required. The 2x4-fiber management panel has cutouts for two combiner/splitter units
and can accommodate two radio shelves.
Table 3 - 8 Fiber Optic Jumpers
JUMPER TYPE PART NO. APPLICATION
FC to LC 3EM07651AA-AK TERMINAL
SC TO LC 3EM07646AA-AK TERMINAL
LC TO LC 3EM07641AA-AK REPEATER
