Logging Into the Switch Using Secure Shell
OmniSwitch 6800/6850/9000 Switch Management Guide December 2007 page 2-13
Secure Shell Application Overview
Secure Shell is an access protocol used to establish secured access to your OmniSwitch. The Secure Shell
protocol can be used to manage an OmniSwitch directly or it can provide a secure mechanism for
managing network servers through the OmniSwitch.
The drawing below illustrates the Secure Shell being used as an access protocol replacing Telnet to
manage the OmniSwitch. Here, the user terminal is connected through the network to the switch.
The drawing below shows a slightly different application. Here, a terminal connected to a single
OmniSwitch, which acts as a Secure Shell client is an entry point to the network. In this scenario, the
client portion of the Secure Shell software is used on the connecting OmniSwitch and the server portion of
Secure Shell is used on the switches or servers being managed.
Terminal
OmniSwitch
Network
Secure Shell
Secure Shell Used as an Access Protocol
OmniSwitch as a Secure Shell Client
Network
Secure Shell
Access Protocol
Secure Shell
OmniSwitch Secure
Shell Client
Secure Shell
Server
Terminal
