8AL90344ENAAed01 10
OmniTouch™ 8128 SE WLAN Handset
IMPORTANT: The handset may retain small metal objects around the earpiece region.
Case
The plastic cover parts are made of durable PC/ABS material.
The WLAN Handset has the enclosure protection IP44, and fulfills IEC 60068-2-32,
procedure 1, which makes it drop proof from 1 meter onto concrete. Ascom approves
12 drops from 1.5 meter.
Antenna
The antenna is integrated inside the handset.
Display
The display is an illuminated 28 x 35 mm, TFT display.
8 Five-way navigation key
Navigation key with Left, Right, Up, Down, and Confirmation (in the middle). It
is also possible to program these keys for shortcuts, except the middle key.
The Up is by default a shortcut to the Inbox, and Down is a shortcut to Call
contact. See also 7.4.3 Define Navigation Key on page 39.
9 Voice mail access
1
A quick access to the handset’s Voice mail by long press.
10 Key lock and upper/lower case
Combined key lock to lock the keypad and upper/lower case. This key is to
lock the keypad in combination with the soft key “Lock”. This key is also for
switching between upper/lower case and digits.
11 Microphone
12 Space
To add space between text.
13 Sound off key
To turn on/off audible signals in standby mode, or silencing the ring signal at
incoming call. During a call, a long press on the key/button changes between
microphone on/off. Same mute function as (5) Mute button.
14 Tactile indicators
There are two tactile indicators to indicate the center of the key pad.
15 End key and On/Off
Combined button; to end a call, to return to standby mode, and to switch the
handset on/off by long press.
16 Color display
The full graphic type display is 176 pixels wide and 220 pixels high. The
display has multiple colors and backlighting.
17 Headset connector
The headset connector is used to connect a headset. It is protected against
dust by using the headset connector cover.
18 LED
Indicates incoming call, low battery, and charging.
1. This feature is system dependent.
