8AL90344ENAAed01 39
OmniTouch™ 8128 SE WLAN Handset
7.4.3 Define Navigation Key
1 Press “Menu”.
2 Select “Shortcuts” in the menu.
3 Select “Navigation keys”.
4 Select “Up”, “Down”, “Left”, or “Right”.
5 Select “Function”, and press “Select”.
6 Select function from list, and press “Back”.
7 Select “Value” (only for some of the functions), and press “Select”. Enter a value,
for example a number. Press “OK”.
8 Select “Control question”, and press “Select”. It is off by default.
If the control question is enabled, a dialog window “Proceed?” is displayed when
pressing the defined key. Press “Yes” to proceed.
9 Press “Save”.
7.4.4 Define Multifunction Button
The Multifunction button can be defined with two different functions, a long press
activates one function, and a double press activates another function.
1 Press “Menu”.
2 Select “Shortcuts” in the menu.
3 Select “Multifunction button”.
4 Select “Long press”, or “Multi press”.
5 Select “Function”.
6 Press “Select” to select function.
7 Select function from list.
8 Press “Select” and then press “Back”.
9 Select “Value” (only for some of the functions), and press “Select”. Enter a value
for example a number. Press “Back”.
10 Select “Control question”, and press “Select”. It is off by default.
If the control question is enabled, a dialog window “Proceed?” is displayed when
pressing the defined button. Press “Yes” to proceed.
11 Press “Save”.
7.5 Settings
7.5.1 Sound and Alert Settings
Adjust the Ringer Volume
1 Press “Menu”.
2 Select “Settings” in the menu.
3 Select “Sound & Alerts”.
4 Select “Volume”.
5 Use the Navigation key to adjust the volume. Press “OK” to save the setting.
NOTE: It is also possible to adjust the ringer volume with the volume buttons in idle
mode.
NOTE: If a handset restriction is enabled, it might not be possible to set the ring
volume to “Silent”, see the Configuration Manual for the handset.
