Note:
Due to hardware, there is a limit in the number of channels that you can configure.
You can configure the following numbers of channels:
• DECT EUROPE, LATAM, CHINA: 1, 2, 4, 5, 8, 10 channels
• DECT US: 1, 2, 4, 5 channels
• PWT: 1, 2, 4, 5, 8 channels
4.13.1.9 Initialization
Once the IBS finishes the downloading, the system starts the initialization.
The system synchronizes the signals of the IBSs so that handovers are possible. The system selects
the T0, T2, or CPU main board clock as the source.
Then the system sends the following data:
• Fixed part capabilities (Full slot, frequency control, page repetition, setup on dummy, basic A field
setup): value sent = 0x007910
• Line length: Short line
• Frequency plan (2 bytes)
Some countries have shifted DECT frequencies. In order to be compatible with all frequency bands in
the different countries, 4 types of initialization of frequency plans are available:
Europe, Latin America, The United-States and China.
table 4.7: RF Band Europe
Channel TX Freq RX Freq
0 1897.344 1898.206
1 1895.616 1896.480
2 1893.888 1894.752
3 1892.160 1893.024
4 1890.432 1891.296
5 1888.704 1889.566
6 1886.978 1887.840
7 1885.248 1886.112
8 1883.520 1884.384
9 1881.792 1882.656
Note:
By default, all frequencies used
Value sent to IBS: 0x3FF
0000 0011 1111 1111
Chapter
4
Installation and Cabling
3EH21123USAA - Ed. 01 - April 2017 - Installation Manual 128/207
