2.4 Equipment
2.4.1 Boards and Options
The following table lists the boards available on OXO Connect Small, Medium, Large.
For boards not in the catalogue anymore, see the technical communication on hardware and software
compatibility.
Board Function Optional boards Connections
APA2
APA4
APA8
2, 4 or 8 analog trunk line inter-
faces
GSCLI: Ground Start
signaling
CLIDSP: CLIP local
management
Analog trunk line (TL), TL-
PS diversion
BRA2-2
BRA4-2
2 or 4 T0 basic accesses ISDN network
ISDN-EFM T0/S0 forward-
ing box
PowerCPU EE Processing Unit, MSDB (Mass
Storage Daughter Board) 8 GB
equipped with eMMC (embed-
ded Multi-Media Card), 512 MB
DDR2 RAM.
HSL1, HSL2: intercon-
nection with expansion
modules
AFU, AFU-1: (Auxiliary
Function Unit)
Mini-MIX providing two
Z (Analog Extension)
ports and two T0 (ISDN
Basic Rate) accesses
ARMADA VoIP32, AR-
MADA VoIP64: VoIP
channels
Lanswitch or Ethernet ter-
minal
Please-wait message play-
er
Tuner for background mu-
sic
Alarm
Doorphone
Loudspeaker
General call ringer
ISDN-EFM T0/S0 forward-
ing box
Pulse metering device
OMC
LanX8-2
LanX16-2
8 or 16 port Ethernet 10/100 BT
(of which 1 or 2 10/100/1000 BT
ports on LanX-2 boards)
@ Phones, Hub, Lanswitch,
PC, etc.
PowerMEX
(equipped with
an HSL1
board)
Extension module controller
MIX244-2
MIX448-2
MIX484-2
2 or 4 T0 basic accesses + 4 or
8 UA interfaces + 4 or 8 Z inter-
faces
ISDN network, analog Z
terminals and Alcatel-Lu-
cent 9 series
Chapter
2
Hardware: Platform and Interfaces
3EH21123USAA - Ed. 01 - April 2017 - Installation Manual 24/207
