OXO Connect
Compact
12V, 4-hour, stack version 1 battery 3EH 76177 AA
12V, 8-hour, stack version Up to 2 batteries 3EH 76177 AD
Note:
The external battery units for OXO Connect Small, Medium, Large platforms are pre-wired and delivered with inter-
battery connectors.
In addition, you will need:
• 12V - 7Ah batteries (reference: 3EH 76156 AA)
• A connection kit (reference: 3EH 75031 AA) for connecting the external battery unit to the OXO
Connect platform.
4.3.3.3 Power Supply Reference
Type Reference
110-230V power supply for OXO Connect S platform 3EH 05009 AC
230V power supply for OXO Connect M platform 3EH 05012 AC
110V power supply for OXO Connect M platform 3EH 05010 AC
230V power supply for OXO Connect L platform 3EH 05013 AC
110V power supply for OXO Connect L platform 3EH 05011 AC
4.3.3.4 Installation of External Batteries for OXO Connect Small, Medium, Large Platforms
You must first prepare the external battery unit for use and then connect this unit to the platform. These
two phases of installation are presented separately below.
You will have to choose the appropriate preparation procedure, according to whether you have a rack
or stack version of the external battery unit.
The connection procedure is the same for OXO Connect M and OXO Connect L platforms, but is
different for OXO Connect S platforms.
4.3.3.4.1 Preparing an External Battery Unit (Rack Version)
Before starting the installation, note that:
• External batteries must be of the same type, must be supplied by the same manufacturer and be
from the same batch run.
• Batteries must be charged prior to installation.
Chapter
4
Installation and Cabling
3EH21123USAA - Ed. 01 - April 2017 - Installation Manual 60/207
