Alcatel IPUP A100 - RS 232 or RS 485 Link Wiring

B 70
1 / 1
Alcatel Vacuum Technology France --- IPUP A100 Instruction manual
RS 232 or RS 485 link wiring
At first power---on, the user will find the initial factory---set configuration
(see C 50).
The setting can be modified through the corresponding monitoring
menu (see C 90).
CONNECTOR WIRING
RS 232 / 485
6 7 8 9
2 3 4 51
(Reception data) (RS 232) RD TD (Transmission Data (RS 232)
GND (Ground)
V(+) (RS 485)
V(--) (RS 485)9--pin male DB connector
The syntax of commands and messages is dealt with in a separate
chapter (see C 90).
EXAMPLES OF POSSIBLE
CONNECTION
Link RS 232 with a single
monitoring system
6
6
8
9
2
3
4
5
1
6
6
8
9
2
3
4
5
1
