Alcatel Vacuum Technology France --- IPUP A100 Instruction manual
Use of the serial link
MONITORING SYSTEM
PARAMETER CONFIGURATION
Setting Action Display
Access to “SETTING” menu
Enter the menu by pressing SET.
Press the + key repeatedly to access
the SETTING menu.
Validate with the ENTER key.
Access to the parameter settings
by the ”SERIAL LINK” menu
Press the + key repeatedly to access
the SERIAL LINK menu.
Validate with the ENTER key.
Access to the parameter to be
modified
Modify the chosen parameter with +
or --- key.
Validate the setting with the ENTER
key.
Return to main menu with SET key.
DEFINITION MENU
SETTING
MAINTENANCE
MANAGEMENT
SETTING
SERIAL LINK
N2 FLOW SENSOR
PRESSURE
2 STOP BITS : DISABLED
SERIAL LINK
TYPE : RS 485
ECHO : ENABLED
SPEED : 9600
PARITY : NO
ADDRESS : 0
