Alcatel Vacuum Technology France --- IPUP A100 Instruction manual
Use of the monitoring system for
pumping operation
l Study the preliminary precautions (See B 00).
l The performance and the operational safety of this product is
guaranteed provided that it is used within normal operating
parameters defined in this manual.
l The pump is tested and filled with a synthetic oil charge at factory.
Do not modify the oil level.
OPERATION SETTING
Preliminary adjustments
Adjust the voltage on the Amat SPI connector (pins 15---16) (see B 60)
between 0 and 10 V, to adapt the rotation speed.
The speed decreases from 0 V (100 Hz) to 8 V (20 Hz) and is constant
between 8 V (20 Hz) and 10 V (20 Hz).
l If no voltage is set on the Amat SPI connector (pins 15---16), then
the pump will run at nominal speed (100 Hz).
Check that the RT1 electrical switch is on the “1” position.
Neutral gas purge control
(IPUP A100P version only)
To ensure that the gas purge comes on as soon as the pump starts,
set the CMD PURGE menu to DISABLED.
This selection does not allow the user to stop the gas purge while
pump is running.
To start or stop the gas purge during pumping, set the CMD PURGE
menu to ENABLED.
The purge will start or stop by pressing the PURGE control key located
on the hand held display module.
When the purge gas is selected, the message N2 is displayed on the
hand held display module.
