Alcatel Vacuum Technology France --- IPUP A100 Instruction manual
First level of troubleshooting
When a problem occurs, the user is informed by:
l the relevant fault indicator light which is located on the front panel:
yellow and green lit in case of warning, red lit in case of hazard
(followed by a pump stop),
l the display of fault message if the hand held display module is
connected,
l a message via the RS 232 / 485 link.
MAINTENANCE TIME
MONITORING
Depending on the programmed values, when operating time for
maintenance is reached, the corresponding warning message will be
displayed in alternance with the operating parameters.
The yellow and green indicators are illuminated on the front panel.
Press the
SET button during the pumping and the programmed
operating times for the components will be displayed.
This information can be read at any time using the
MAINTENANCE
menu.
GENERAL ELECTRICAL
DIAGRAM
When troubleshooting the pump (using D 20) you may need to check
the electrical components of the IPUP A100 (see G 10).
